Pov-Ray (Persistence of Vision Ray Tracer) is software that renders a 3-D image from a script. Pov-Ray was initially started in the 1980s by David Kirk Buck and Aaron A. Collins. In the 1990s, development was handled by a team of extremely talented and dedicated programmers who have produced upgraded versions of this remarkable, and free software.
Pov-Ray is covered in a very good article in Wikipedia. The Wikipedia article includes a superb, public domain Pov-Ray rendering, shown here:
Before you try any project like this, you've got to start with something small. Every Pov-Ray newbie starts with a simple scene consisting of a ball, placed over a plane.
Here is an example:
The Pov-Ray script for the scene is:
global_settings { assumed_gamma 1.0 }
// ----------------------------------------
camera {
location <5.0, -12.0, 2.0>
up z sky z
look_at <0.0, 0.0, 0.5>
angle 40
}
sky_sphere {
pigment {
gradient z
color_map {
[0.0 rgb <0.6,0.7,1.0>]
[0.2 rgb <0.2,0.3,0.9>]
}
}
}
light_source {
<3, 1, 2>*1000
color rgb <2.2, 1.8, 1.5>
}
// ----------------------------------------
plane {
z, 0
texture {
pigment {
checker
color rgb 1, color rgb 0
}
}
}
sphere {
z*1.4, 1
texture {
pigment { color rgb 1 }
finish{
diffuse 0.3
ambient 0.0
specular 0.6
reflection 0.8
}
}
}
Every Pov-Ray script contains command lines that specify a camera, one or more sources of light, and one or more objects. The camera, light source, and objects are provided coordinates on an imaginary 3-D grid. The Pov-Ray script calulates the pixels on an imaginary camera screen (corresponding to the final image) receiving rays of light that leave the light source(s) and travel through scene. The color of the light that reaches each pixel position on the camera is determined by the properties of the objects in the scene.
Tomorrow, I'll explain a little more about the mechanics of building and executing a Pov-Ray script (called a .pov script) from within the Pov-Ray application.
- © 2010 Jules Berman
